TMRC SUZUKI DF300 V3 OUTBOARD — STL PACK
Direct bolt-on upgrade for the TMRC 3660 V3 platform.
The next evolution of the TMRC outboard lineup. The Suzuki DF300 V3 is engineered as a direct bolt-on upgrade for the TMRC 3660 V3 platform and designed specifically around the proven TFL lower unit setup.
This version features a redesigned mounting structure for improved rigidity, cleaner fitment, and better long-term durability under high-power setups. Built for serious RC offshore applications.
Specifications
- Motor Compatibility: 3660 brushless water-cooled setup
- Lower Unit Compatibility: TFL lower unit
- Drive Shaft: 4 mm stainless — length TBD
- Lower Unit Mounting Hardware: 25 mm M2 screws
- Steering / Swivel Bolt: M3 × 80 mm
- Platform: Direct bolt-on to existing TMRC V2 system
What's Included
- Suzuki DF300 V3 cowling
- Updated V3 midsection
- Swivel bracket components
- Mounting hardware locations integrated into the design
- Trim-compatible architecture
- Direct bolt-on compatibility with the TMRC 3660 V2 system
- STL files for 3D printing
Recommended Print Settings
- Material: PETG / ASA / ABS
- Walls: 5
- Infill: 5% (3D Honeycomb)
- Layer Height: 0.2–0.28 mm
- Hardware: Heat inserts strongly recommended
- Increase infill around high-stress mounting areas on aggressive setups
Filament
Printed in SUNLU PETG. Get it here (affiliate link): https://store.sunlu.com?sca_ref=11554757.OetPZf1JlD&utm_source=sunluaffiliate&utm_medium=sunluaffiliate&utm_campaign=sunluaffiliate
Required Non-Printable Components (Not Included)
These parts are not printable and must be sourced separately:
- 3660 Brushless Motor (2150KV) — https://amzn.to/3OrRagp
- Lower Unit — TFL B54210 H-KIT-E — https://tflnorthamerica.com/product/tfl-b54210-h-kit-e-for-b54210/
-
4.0 mm Stainless Steel Drive Shaft — https://amzn.to/4q64TGN
Length TBD - Elastic Shaft Coupler (5 mm → 4 mm) — https://a.aliexpress.com/_msaWfy5
-
Reference Motor Mount Screw (Optional) — https://www.mcmaster.com/91273A349/
Any standard M3 screw of suitable length may be used
Assembly Video
Watch the TMRC V3 outboard assembly walkthrough on Instagram
Designed For
- High-performance RC center consoles
- Catamarans
- Offshore race builds
- Twin, triple, quad, and quint outboard setups
- Scale replica projects
Digital Download Only
No hardware, motors, electronics, shafts, couplers, or drive components included.
