TMRC Raptor 30CC STL Pack — Prototype Drop

Name: TMRC Raptor 30CC STL Pack — Prototype Drop
Brand: Tremendous Marine RC
Price: 39.99 USD
Availability: InStock

⚠️ PROTOTYPE DISCLAIMER — READ BEFORE BUYING

This boat has NOT been printed by TMRC yet. We have designed and printed many boats in the past, but this one has not gone through our usual test print and water test. You are buying the first-release files as-is, at a discounted prototype price for exactly that reason.

Minor fit-ups or design revisions may follow once we print it ourselves. Every prototype buyer receives the updated files by email when the final version is released. If you want a fully print-tested pack, pick one from the Ready to Print collection.

DISCLAIMER

This is a digital STL file. No physical product will be shipped.
All sales are final. Due to the nature of digital downloads, no refunds or exchanges are offered.
Files are for personal use only. Redistribution, resale, or sharing of the files or printed parts is prohibited.
This is an original Tremendous Marine RC design and is not affiliated with, endorsed by, or associated with any real-world boat manufacturer.

TMRC RAPTOR 30CC

A 30-inch offshore center console with a hardtop, leaning post and single outboard — built for the TMRC V3 outboard platform and sized to print on a 250 × 250 mm bed.

The Raptor 30CC brings the full center-console look to a compact hull. Stepped sheer, forward seating, a hardtop with rod holders, a leaning post with twin seats, and a single outboard off the transom. It is designed for RC builders who want a fast, scale-looking boat that fits a standard desktop printer.

Runs the TMRC V3 outboard — ready to bolt up

The transom is designed around the TMRC V3 outboard platform. Any V3 outboard — Merc 300X, Merc Pro 400, Verado 350, Yammy 425 or DF300, as an STL pack, a fully printed ABS-CF motor, or a complete drive kit — bolts straight on with no adapter plate or modification. Shop V3 outboards →

Specifications

Hull Length: 30 in (762 mm)
Length Overall (with outboard): 37 in (940 mm)
Beam: 10.7 in (272 mm)
Height (keel to hardtop): 11.8 in (300 mm)
Drive: Single outboard — TMRC V3 platform, bolt-on
Style: Offshore center console with hardtop
Designed for: FDM 3D printers, 250 × 250 mm build area

What's Included

Complete hull and deck with V3-ready transom
Center console and hardtop with rod holders
Leaning post with twin seats
Forward seating and bow cushion
Scale outboard body (display — V3 motor, lower unit and electronics sold separately)
Trim tabs and deck details
Complete STL file pack, split for 250 × 250 mm printers
License & Disclaimer PDF with suggested print settings

Suggested Print Settings

Our usual TMRC settings. This design hasn't been test-printed by us yet, so treat them as a starting point and check transom fit before committing to the whole hull.

Material: PETG / ABS / ABS-CF
Nozzle: 0.4 mm
Walls: 4
Infill: 5% (3D Honeycomb or gyroid) — 15–20% around the transom and motor mount
Layer Height: 0.2–0.28 mm
Top / Bottom: 4 / 4
Supports: Only where required (bow sections, hardtop, console overhangs)
Assembly: Glue sections with CA or epoxy, fill and sand seams, seal the hull interior before electronics go in
